Forsis EXPERT SE, 21,5″ LCD TFT Industrial Computers

A large, clear 21.5" Full HD touchscreen characterizes the Expert 2150 SE FHD industrial computer. The sturdy stainless steel housing is robust and protects the inside of the computer from dust and moisture. The front has an IP69K protection class and is therefore protected against water even at high pressure. The front and back of the "iC T IP69K" model have the IP69K standard. A variety of interfaces allow easy integration, there are also multiple processors and operating systems available.

Add to wishlist Downloads

FORSIS EXPERT 2150 SE FHD: Large-Scale Work

  • brilliant: large 21,5“ touchscreen
  • multi-faceted: Windows, Windows Embedded, IGEL
  • packed: many additional options

The IPC series from Forsis are characterized by their versatility. You can choose between different operating systems: Windows 7 or 8, Windows Embedded 7 or 8 and for some versions an additional IGEL version (eg for Linux) is possible. You can choose between different Intel processors as needed. Easily integrate industrial computers with numerous interfaces: 2 x RS232, 2 x USB2, 2 x USB3, DP, HDMI, VGA, 2 x Ethernet 1000 Mbps, optional: RS422 / 485. The IPCs have additional slots: Mini PCIe 1 x full size, 1 x half size.

Expert 2150 SE FHD stationary with 21,5“ display:

iC T:
CPU: Intel Celeron 1047UE, 2 x 1,4 GHz, 4 GB RAM, SSD 128
OS: Windows 7, 8; Windows Embedded 7, 8; IGEL

iC T IP69K: (Front- und Anschluss-Seite IP69K)
CPU: Intel Celeron 1047UE, 2 x 1,4 GHz, 4 GB RAM, SSD 128
OS: Windows 7, 8; Windows Embedded 7, 8; IGEL

i3 T:
CPU: Intel Core i3 3217UE, 4 GB RAM, SSD 128 GB
OS: Windows 7, 8; Windows Embedded 7, 8; IGEL

i7 T:
CPU: Intel Core i7 3555LE, 4 GB RAM, SSD 128 GB
OS: Windows 7, 8; Windows Embedded 7, 8

There are a number of additional options available for the industrial computers of the Expert FHD series: WLAN, Bluetooth, UMTS / LTE, RFID reader, etc.


Technical specification

Product Category Fixed Computers
Category Industrial Computers
Manufacturer Forsis
Display Size 21,5"
Communication Interface USB, Serial, VGA, HDMI, Display Port, Ethernet, Bluetooth, WLAN, UMTS/LTE
Operating System WES 7, WES 8, WIN 7, WIN 8, IGEL
CPU Intel Celeron 1047UE|Intel Core i7 3555LE
Memory 4 GB RAM|8 GB RAM|128 GB SSD
Expansion Mini PCIe
Device Material V2A / V4A
Surface Treatment outside: brushedi, inside: polished
Sealing Front IP69k
Sealing Back IP65|IP69k
Operating Temperature -5°C to 45°C
Humidity 0% to 90%
Touchpanel analog resistive touch screen
Special Features The features of the SE series are:- Tight according to protection class IP68.- LCD sizes up to 21.5"- Plug exit downwards- Cable exit protected according to IP65 - no soldering work.- Many standard interfaces are available.

Downloads

Datasheet Forsis Expert 2150 SE FHD i3 T (EN) Datasheet Forsis Expert 2150 SE FHD i7 T (EN) Datasheet Forsis Expert 2150 SE FHD iC T (EN) Datasheet Forsis Expert 2150 SE FHD iC T IP69k (EN)
