Zebra TC52x-HC Series Mobile Computers

  • future-proof: OS upgradeable through Android 14, Wi-Fi 6 (TC52ax-HC)
  • accurate: SE4720 imager for 1D, 2D and Digimarc capture, UDI mode
  • straightforward: programmable red emergency button
  • convenient: high-brightness FHD display, glove-enabled; optimized voice communication; can be used as desktop PC
  • durable: disinfectant-ready, unibody design, 1.2 m drop resistance, IP65

The TC52x-HC series’ mobile terminals are designed by Zebra specifically to improve healthcare workflows. They address the professional requirements of medical staff at all levels. Other medical fields, such as laboratories or pharmaceutical companies, also benefit from the advanced data technology. The two handheld terminals TC52ax-HC and TC52x-HC can be used to optimize processes. Digital data capture, reliable mobile network connections and versatile voice communication options make work easier in healthcare areas.

Add to wishlist
Downloads

ZEBRA TC52X-HC SERIES: Future-oriented Mobile Computers for the Healthcare Sector

The Zebra TC52x-HC mobile computer series equips medical personnel with a handy computing solution. It directly addresses the needs of the healthcare sector, enabling more flexible work processes and ensuring patient safety.

The Qualcomm Snapdragon 660 is an octa-core processor with a clock frequency of 2.45 GHz. It offers 4 GB RAM and either 64 GB (TC52ax-HC) or 32 GB (TC52x-HC) flash storage. The CPU provides high computing power and ensures that business applications run smoothly. Storage capacity can be additionally expanded by up to 256 GB using a microSD card. The OS solution is designed for long-term use and can be upgraded to Android 14.

Instead of investing in an additional stationary computer or notebook, simply convert the mobile terminals Zebra TC52ax-HC and TC52x-HC into a PC workstation. With the “Workcloud Communication” cradle they can be used as desktop computers by being connected to a large screen, keyboard, mouse, printer, etc. This straightforward solution saves costs, energy, and space.

Zebra’s TC52x-HC series’ healthcare mobile computers feature a 5-inch display with full HD resolution. With a brightness of up to 600 nits, the screen is highly visible both indoors and outdoors. The brightness automatically adjusts to the ambient light. The user-friendly touchscreen can be operated with gloves, which are often used in medical environments, and it can even be navigated when it gets wet.

In all areas of the healthcare sector—from correct patient identification to supply management—digital data acquisition has become an important factor. The TC52x-HC healthcare PDT series is therefore equipped with the advanced SE4720 scan engine. It enables maximum efficiency collecting 1D, 2D and Digimarc codes in any condition. Even barcode labels on curved or uneven surfaces, for example on small tubes or packages filled with liquids, are captured accurately. Especially for applications in healthcare, the mobile computers offer a UDI mode. In this mode, UDI codes on medical products are automatically recognized and captured.

The TC52ax-HC and TC52x-HC mobile terminals are equipped with a 13-megapixel rear camera. Due to the large aperture, pictures can be taken even in low-light conditions. The devices also have a 5-megapixel front camera, which can, for example, be used for video calls.

Three microphones, high-quality loudspeakers, and noise cancellation ensure first-class audio quality. Choose from various “Workcloud Communication” push-to-talk voice communication solutions as required.

Zebra’s TC52x-HC series’ mobile computers feature a red, programmable button for emergency situations. It provides instant access to a defined phone number or application. Another useful feature is the “device tracker”. If a terminal has been accidentally misplaced, it can be easily located, even if it is switched off.

Zebra’s TC52x-HC series is equipped with up-to-date wireless technology. The TC52ax-HC offers Wi-Fi 6, providing reliable high-speed network connectivity. Both models feature MU-MIMO technology. The “WorryFree WiFi” application ensures optimized wireless network performance and enables customized configuration. In addition, the smart devices are equipped with Bluetooth 5.0 and provide easy tap-to-pair functionality via NFC.

The removable PowerPrecision batteries enable runtimes of up to 14 hours per charge. With Zebra’s “PowerPrecision Console”, battery health is constantly monitored. The Zebra TC52x-HC series’ mobile computers feature hot-swap capability and fast-charge technology.

The handhelds Zebra TC52ax-HC and TC52x-HC are made for a long service life. They can withstand drops from a height of 1.2 m. The unibody design ensures high durability and a high level of hygiene. The mobile computers are resistant to disinfectants and can be wiped regularly with harsh cleaning agents. Touchscreen and scan window are both made of Corning Gorilla Glass. The devices are sealed against the ingress of dust and liquids in accordance with protection class IP65.
